T.C Electronic Finalizer Express Studio Mastering Processor

Item Details:

• Brand: T.C. Electronic
• Model: Finalizer Express Studio Mastering Processor
• Type: Sound Mastering Equipment
• Specifications:
  • Digital Inputs and Outputs
    • Connectors: XLR (AES/EBU) RCA Phono (S/PDIF)
      Optical (Toslink)
    • Formats: AES/EBU (24 Bit), S/PDIF (20 bit), EIAJ CP-340, IEC 958m EIAJ Optical (Toslink)
    • Output Dither: HPF TPDF dither 16, 20 and 24 bit
    • Sample Rates: 44.1 kHz, 48 kHz
    • Processing Delay: 0.2 ms @ 48 kHz
    • Frequency Response DIO: DC to 23.9 kHz + 0.01 dB @ 48 kHz
    • Compressor THD+N: -122 dB (0.00008%) @ 10 dB Compression, 20 Hz to 20 kHz
  • Analog Inputs
    • Connectors: XLR balanced (pin 2 hot)
    • Impedance: 20 kohm
    • Max. Input Level: +22 dBu (balanced)
    • Min. Input Level (for 0 dBFS): -10 dBu
    • Sensitivity: @ 12 dB headroom: -22 dBu to + 10 dBu

    • A to D Conversion: 24 bit (1 bit, 128 times oversampling)
    • A to D Delay: 0.8 ms @ 48 kHz
    • Dynamic Range: >103 dB (unweighted), >106 dB(A)

    • THD: -95 dB (0.0018%) @ 1 kHz, -6 dBFS (FS @ +16 dBu)
    • Frequency Response: 10 Hz to 20 kHz +0/-0.2 dB
    • Crosstalk: <-8- dB, 10 Hz to 20 kHz typical -100 dB @ 1 kHz
  • Analog Outputs
    • Connectors: XLR balanced (pin 2 hot)
    • Impedance: 100 ohm (active transformer)

    • Max. Output Level: +22 dBu (balanced)
    • Full Scale Output Range: -10 dBu to +22 dBu
    • D to A Conversion: 24 bit (1 bit, 128 times oversampling)
    • D to A Delay: 0.57 ms @ 48 kHz
    • Dynamic Range: >100 dB (unweighted), >104 dB(A)

    • THD: -86 dB (0.005%) @ 1 Khz, -6 dBFS (FS @ +16 dBu)
    • Frequency Response: 10 Hz to 20 kHz: +0/-0.5 dB
    • Crosstalk: <-60 dB, 10 Hz to 20 kHz
      Typical -0- dB @1 kHz

Conditions:

• Item is used and in good condition
• Item has been tested and is functioning properly
• Item may have minor scratching and scuffing from normal use
• Item does not include any additional accessories
